Electric Chain Hoist 10 Ton

electric chain hoist 10 ton,A.Aluminium Body B.Quality chain is supplied by FEC Japan C.Most tensile safety hooks without break D.Compact and high efficient motor with heat protection device E.Choose double speed motor,big power and different voltage are available F.Push button is with 24V low voltage to guarantee safety and limit switch system G.Sensitive break system.Friction disk without asbestos H.Choose presice process of high tensile helix gear working system to keep lower noise I.Enough Chain bucket set.space to suit different lifting longth J.IP54 protection on electric hoist for dust and water protection K.Ins Class:F

Send InquiryChat Now
Product Details

electric chain hoist 10 ton

1.Product Introduction of motor electric chain hoist 10 ton

This electric chain hoist has Japan FEC80 ultra heat-treated steel alloy chain and side magnetic braking device,which can offer the instant brake.

2.Product parameter of electric chain hoist 10 ton

Type

Capacity
     (Ton)

Standard
     Lifting
 Height(m)

Lifting
  Speed    (m/min)

Lifting Motor

Power

Rotation
  Speed
  (r/min)

Phase

Voltage
     (V)

Frequency
     (Hz/s)

HKD00501S

0.5

3

6.8

0.75

1440

3

200-600

50

HKD0101S

1

3

6.6

1.5

1440

3

200-600

50

HKD0102S

1

3

3.4

0.75

1440

3

200-600

50

HKD01501S

1.5

3

8.8

3.0

1440

3

200-600

50

HKD0201S

2

3

6.6

3.0

1440

3

200-600

50

HKD0202S

2

3

3.3

1.5

1440

3

200-600

50

HKD02501S

2.5

3

5.4

3.0

1440

3

200-600

50

HKD0301S

3

3

5.4

3.0

1440

3

200-600

50

HKD0302S

3

3

4.4

3.0

1440

3

200-600

50

HKD0303S

3

3

2.2

1.5

1440

3

200-600

50

HKD0502S

5

3

2.7

3.0

1440

3

200-600

50

3.Product feature and application

electric chain hoist 10 ton1564.jpg



The electric chain hoist features a mechanism for winding the chain, as well as a hook to which you will attach the load that you need to lift. Most of the time, the machine is easily portable and will feature clamps that it will use to attach to an overhead structure when in use. It also features a control panel, which is generally easy enough that you can use it with a single hand. You can raise or lower the item you are lifting very simply, and you can do so slowly so you don’t damage it at all.



electric chain hoist 10 ton2071.jpg

They are made by hot forging and heat treatment.

Advantages:meets the demands on strength amd hardness,durable and strong,not easy to break

and wear.360 degrees rotation and safety ensure the operation safety.




electric chain hoist 10 ton2284.jpg



Light weight and small volume of high-performance motor. Rotating speed can be up to 3000r.m.p. High starting torque and high energy efficiency. Sustained rate of electric connection reaches up to 60%, which can meet the demand for high frequency handling.



4.Product Qualification of the electric chain hoist

electric chain hoist 10 ton2596.jpg




Kaidao has the technology department, the sales department, the after sale department and the production department,each department works well together.




electric chain hoist 10 ton2751.jpg



Kaidao factory has CNC workshop,has the ability to produce all parts of the electric chain hoist and finish the workpiece.


electric chain hoist 10 ton2875.jpg



Kaidao has reliable packing,the standard export plywood case can protect the product very well.




●Deemed continuous improvement as our permanent pursuit

●We have introduced many advanced equipments and mature techniques,to meet various of custome rs’ requirements

●We can adjustment the price according to your market demand’s changes,and also can l  aunch  a serie s of promotional activities in a bad economic environment.

●We will do our best to deal with the problems our customers encountered, in order to  ensure our customers' satisfaction and also improve our better reputation
