Basic Info
Model NO.: KDFB series
Type: Electric Chain Hoist
Lift Speed: 1.6-6.6m/min
Chain Falls: 1-4
Condition: New
Voltage: 200V--600V
Work Class: M4
Transport Package: Plywood Cases
Origin: China
Application: Double Beam Crane, Gantry Crane, Bridge Crane, Tower Crane, Single Grinder Crane, Lifting Platform, Small Crane
Sling Type: Chain
Maximum Lifting Height: >20m
Certification: CE, ISO9001:2000
Color: Yellow
Phase: 3
Trademark: ELK
Specification: 1--2 CBM
HS Code: 8425110000
Product Description
ELK 35000kg Explosion-Proof Electric Chain Hoist with Electric Trolley
Specialized In Customized Design Manufacture
ELK Electric Chain Hoists with Hook with Slipping Clutch -- Specification Parameters Table :
Notes **: More Complete Technical Parameters & Size Specification Catalogue , pls Contact us ,we will send to you our newest Completely Technical Datas by E-mail .
ELK Electric Chain Hoists with Slipping Clutch -- Factory Views & Certificates :
ELK Electric Chain Hoists with Slipping Clutch-- After-sale Services-- within 24 Hours:
(1)....Before--Sale Service :
01..Quality Control: Strictly Production Request base on signed contract ;
02..Delivery Time: Guarantee within contracted delivery time ;
03..Photos: Send photos to our customer after finish production and packing ;
04..Packing Details:Give complete packing size table to our customer;
05..Brand: Respect our customers' advice to use our customers' own brand & logo ;
06..Documents:Provide high efficiency service to post you all required customs clearance documents by DHL or TNT .
(2)....After--Sale Service :
01..Reply : Fast reply all your questions on line or by email or by telephone ;
02..Quality Problems:Our factory is responsible for any problems if it is resulted by our reasons (Such as give you free new parts to repair it or give enough some compensation cost to you) ;
03..Safe Operating: Pls remind your customers to respect our Operating Manual to operate our machine rightly, to guarantee Safe when operate our machine ;
*****Chain Maintenance : Must often make the Chain to be Lubricated by Chain Oil :
ELK Electric Chain Hoists with Slipping Clutch--Factory Info & FAQ:
01.Are you manufacturer or trade Company?
--We are a factory founded in 11 Year .
02.How about sample & MOQ policy?
--Welcome sample order. MOQ can be 1 set.
Specialized In Customized Design Manufacture
We are Manufacturer of ELK Electric Hoist with Slipping Clutch : -- High Quality / High Safety :
★★★★★:Basic Description of ELK Electric Chain Hoist with Slipping Clutch : -- High Quality / High Safety :
| ELK® Electric Chain Hoist With Clutch Basic Description: | ||
| (1). | Products Name : | Electric Chain Hoist with Clutch |
| Type: | KDFB | |
| Capacity: | 1-10TON | |
| Lift Height: | 2.5-20M | |
| (2). | Material : | Aluminum. Steel ; |
| (3). | Application : | Overhead Crane,Lift Equipment,Cargo Lift,Wind Power Projects, Etc.; |
| (4). | Certificates : | CE--ISO--SGS; |
| (5). | Brand Logo : | ELK or Customized your logo; |
| (6). | Packing Kinds : | Plywood cases (No Need Fumigation) |
| (7). | Packing Size:L*W*H cm : | Pls Ref. Below Technical Table; |
| (8). | Packing Weights : | Pls Ref. Below Technical Table; |
| (9). | Delivery Time : | Within 10 Days----20 Days; |
| (10). | Work Class : | M5=H4=2M ; |
| (11). | Rating : | 30min ; |
| (12). | Quality Warranty : | 2 Years ; |
ELK Electric Chain Hoists with Slipping Clutch Advantages: : -- High Quality / High Safety :
| ELK Brand High grade : Electric Chain Hoist with Clutch -- Advantages : | ||
| No. | Quality grades | High grade |
| ★ | ELK Clutch Hoist Hot Sale Advantages | (1).Highest Safety;(2).Reliable Quality Performance;(3).Lowest Repair Rate;(4).High Quanlity & Reasonable Price--as Original Manufacturer; (5)Excellent High-efficiency Responsible After-Sale Service. |
| 1 | Slipping Clutch | Automatic Overload Protection--can protect hoist more safe when overload cargo ; |
| 2 | Unique Shape | Unique Shape Design Patent is Reserved by our factory; |
| 3 | Cooling Fan | With Fan--can help motor to be more Easily Heat Dissipation ; |
| 4 | No Limit Spring | This can make Bottom Hook Up Min. Headroom Lower about 80----160mm ; |
| 5 | Ends Outside Shell | Use Aluminum--to be more Light ; |
| 6 | Inner Space | Design inner space--enough to put Built-in Inverter ; |
| 7 | Speeds | Single Speed and Dual Speeds are same body shape; Dual Speeds Hoist use Mitsubish Inverter--Dual Speeds Electric Trolley use 2 speeds type motor ; |
| 8 | No Guide Frame | Can Lift Cargo Slantly within 45 Degree--Never Impact the Top Roof of Hoist Body--To Protect Chain Wheel System ; |
| 9 | Class | Work Class:M5=H4----Rating:30min----ED:50%----IP:55----Work Temp.:-20ºC--40ºC; |
| 10 | Anti-phase Protector | Can protect Electric Parts Safety in case of wiring error ; |
| 11 | Transformer | Hand control voltage:24V/36V/48V/110V; |
| 12 | AC Contactor | Schneider Or Shihlin Brand; |
| 13 | Chain | Japan FEC80 Chain Or Chinese G80 Chain; |
| 14 | Gear | High precision grinding gear; |
| 15 | Hoist & Motor Brand | ELK brand; |
| 16 | Quality Warranty: | 2 Years --(But no include easy quick-wear parts); |
ELK Electric Chain Hoists with Hook with Slipping Clutch -- Specification Parameters Table :| Capacity (Ton) | Standard Lift Height (m) | Lift Speed (m/min) | Power (Kw) | Voltage /Pha se | Trolley Speed(m/min) | Chain Dai.(mm) | Work Class | Weights(Kgs) | Volume(m3) |
| 0.5T | 3m | 6.8 | 0.75 | 200V-- 600V/3P / 50Hz or 60Hz | / | Ø6.3x19 | M5 | 48 | 0.09 |
| 1T | 3m | 6.6 | 1.5 | / | Ø7.1x21 | M5 | 62 | 0.11 | |
| 1T | 3m | 3.4 | 0.75 | / | Ø6.3x19 | M5 | 56 | 0.09 | |
| 2T | 3m | 6.6 | 3 | / | Ø10x30 | M5 | 119 | 0.18 | |
| 2T | 3m | 3.3 | 1.5 | / | Ø7.1x21 | M5 | 78 | 0.11 | |
| 3T | 3m | 5.4 | 3 | / | Ø11.2x34 | M5 | 126 | 0.18 | |
| 3T | 3m | 4.4 | 3 | / | Ø10x30 | M5 | 113 | 0.18 | |
| 3T | 3m | 2.2 | 1.5 | / | Ø7.1x21 | M5 | 115 | 0.18 | |
| 5T | 3m | 2.7 or 4.4 | 3 | / | Ø11.2x34 | M5 | 157 | 0.18 | |
| 7.5T | 3m | 1.8 or 2.9 | 3 | / | Ø11.2x34 | M5 | 186 | 0.27 | |
| 10T | 3m | 2.7 or 4.4 | 3 x 2 | / | Ø11.2x34 | M5 | 341 | 0.58 | |
| 15T | 3m | 1.8 or 2.9 | 3 x 2 | / | Ø11.2x34 | M5 | 475 | 0.66 | |
| 20T | 3m | 1.4 or 2.2 | 3 x 2 | / | Ø11.2x34 | M5 | 615 | 0.97 | |
| 25T | 3m | 1.1 or 1.8 | 3 x 2 | / | Ø11.2x34 | M5 | 648 | 1.23 | |
| 30T | 3m | 0.9 or 1.5 | 3 x 2 | / | Ø11.2x34 | M5 | 960 | 2.42 | |
| 35T | 3m | 0.8 or 1.5 | 3 x 2 | / | Ø11.2x34 | M5 | 1250 | 3.14 |
Notes **: More Complete Technical Parameters & Size Specification Catalogue , pls Contact us ,we will send to you our newest Completely Technical Datas by E-mail .
ELK Electric Chain Hoists with Slipping Clutch -- Factory Views & Certificates :
| 1 | ODM: KAIDAO Company is the Professional Source Manufacturer ; | |
| 2 | International Certificates: CE -- ISO -- SGS Approved; | |
| 3 | Brand : ELK ® | |
| 4 | Factory : 8 Senior Professional Engineers with more than 20 years experiences ; | |
| 5 | Factory Area : Total 5 Workshops ; 6000 M2 | |
| 6 | Annual Output Value:1290 0000 USD----2000 0000 USD ; | |
| 7 | Monthly Output:3000--5000 Sets ; | |
| 8 | Market Percentage: 70% for Export--World Market / 30% for Sale--Home Market; | |
| 9 | Production Scope : | |
| (1) | Electric Chain Hoist with (Slipping Clutch) | 0.5T---------60T |
| (2) | Electric Wire Rope Hoist | 0.5T---------32T |
| (3) | Crane Geared Motor with Buffer | 0.25Kw-----3.75Kw |
| (4) | End Truck | 0.5T----------50T |
| (5) | Crane Wheel Block | GWPW95--GWPW545 |
| (6) | Electric/Manual Trolley | 0.5T----------30T |
| (7) | Hoist Spare Parts:Remote Control-Overload Protector Etc. | 0.5T----------60T |
| (8) | Crane Spare Parts:Power Rail-C Track-Cable Etc. | 0.5T----------50T |
| (9) | Single/Double Girder Crane | 0.5T----------50T |
| (10) | Chain Block | 0.5T----------20T |
| (11) | Lever Block | 0.5T----------9T |
ELK Electric Chain Hoists with Slipping Clutch-- After-sale Services-- within 24 Hours:
(1)....Before--Sale Service :
01..Quality Control: Strictly Production Request base on signed contract ;
02..Delivery Time: Guarantee within contracted delivery time ;
03..Photos: Send photos to our customer after finish production and packing ;
04..Packing Details:Give complete packing size table to our customer;
05..Brand: Respect our customers' advice to use our customers' own brand & logo ;
06..Documents:Provide high efficiency service to post you all required customs clearance documents by DHL or TNT .
(2)....After--Sale Service :
01..Reply : Fast reply all your questions on line or by email or by telephone ;
02..Quality Problems:Our factory is responsible for any problems if it is resulted by our reasons (Such as give you free new parts to repair it or give enough some compensation cost to you) ;
03..Safe Operating: Pls remind your customers to respect our Operating Manual to operate our machine rightly, to guarantee Safe when operate our machine ;
*****Chain Maintenance : Must often make the Chain to be Lubricated by Chain Oil :
ELK Electric Chain Hoists with Slipping Clutch--Factory Info & FAQ:
01.Are you manufacturer or trade Company?
--We are a factory founded in 11 Year .
02.How about sample & MOQ policy?
--Welcome sample order. MOQ can be 1 set.
