                                    3 Ton Wire Rope Hoist

  ELK 3 Ton wire rope electric hoist running speed of 8 meters per minute, the motor has good heat dissipation, long service life characteristics, electric hoist can work long hours in high-intensity work without touching the heat protection, resulting in wire rope electric hoist can not be used. Lifting motor: Electric hoist for the side magnetic three-phase motor, the use of B-class insulation, motor design has a stop or brake side magnetic mechanism, the use of safe and reliable.

 3 Ton wire rope hoist uses a large starting torque conical rotor brake asynchronous motor, no need for additional brakes. Motor load continuity rate of 25%, the motor using B-Class or F-class insulation, motor protection class IP44/IP54, this product using three-stage fixed shaft helical gear transmission structure, gears and gear shafts made of heat-treated alloy steel. The box cover is made of high quality cast iron, tightly assembled and well sealed. The main circuit can be cut off in case of emergency, and with the upper and lower stroke protection of the fire limit device. Ensure the safe operation of electric hoist.

ELK company can also provide samples and design drawings according to customers to produce a variety of non-standard products to meet the different needs of customers. We adhere to the principle that science and technology is the first productive force and strictly implement quality standards, from the procurement of raw materials to the entire process of cargo transport have strict control. Our goal is to achieve a product pass rate of 100%, to ensure that the product quality and excellent.
