Special design: box support frame design

This Chinese Jib crane design can install the support frame assembly on the cantilever assembly in advance, effectively reducing the requirement of installation space and greatly improving the hoist head.

Compared with traditional bushing structure, cassette brace structure can increase the stability of equipment operation, reduce the deflection of cantilever and the vibrating of the load, create a more secure operating environment, reduce the artifact damage rate.

2.ELK Jib Crane 3.jpg

Chinese Jib crane is easy to operate

Chinese Jib crane is convenient for operators to accurately locate the load, easy and efficient.

The top shaft is equipped with precision taper roller bearing and roller assembly, which has a longer service life, providing guarantee for smooth operation.

The triangle support Angle plate of bottom plate minimizes crane deflection and makes it easier to operate when accurately locating load.

Chinese Jib crane is easy to install

The independent support frame component is separated from the cantilever during installation. Chinese Jib crane is easy to install independently.

Embedded bearing assembly greatly reduces the additional clearance required for installation;

Support stands between components and slewing bolt fastening the installation work can be done separately, can be very close to install the jib on top of the roof or obstacle below, minimize occupy the top space, increase the gourd head;

The stop bolt of the hoist car is tightened, which can be installed according to the application changing position.

Top - mounted fully sealed bottom inlet collector assemblies can be pre-installed or later added.Meet the application conditions of 360 ° rotating powering a gourd.

5-30 ELK Crane Motor Hoist33.jpg

Safety: the top positioning pin can effectively prevent the support frame component from moving up unexpectedly.

Full rated load application: preliminary design of dynamic hoist crane for 15% of the rated lifting weight under consideration for hoist, hoist trolley and hook device, the total weight of the crane as 25% of the rated load impact load.Can provide customers with full rated load application of the swing arm crane products.


Chinese Jib crane can choose manual operation or choose electric operation
